iDC iPDU-MC Series
The iPDU-MC series rack iPDU is designed to suit the operational requirements of next-generation datacenters. iPDU-MC Series is a sustainable, upgradeable and maintainable iPDU system which can be re-configured or upgraded hot without affecting the operation of a datacenter.
iPDU-MC series iPDUs are per-outlet metered and per-outlet switchable.
Sustainable
Provide different functions in different stages of business by using hot-swap function modules
Upgradeable
Hot-swap Network Management and Control module is upgradeable
Maintainable
Safe and reliable in-field maintenance without affecting power supply to IT equipment
Key Features
Hardware Features
● Hot-swap NMC (Network Management and Control) module and for easy upgrade and maintenance
● Available with IEC and UK outlets with self-designed locking system for IEC outlets
● 2.8″ LCD screen displays the Current (Amps), Voltage (Volts), Power (kW), Energy Consumption (kWh) and Power Factor
● Independent power supply for the NMC module to ensure accessibility even the breaker tripped when overload occurs
● NMC module can be rotated 180 degrees allowing the iPDU to be mounted in any orientation
● Low-profile UL 489 certified hydraulic circuit breakers to prevent current overload in each branch circuit and keep iPDU running stable
● Daisy-chainable up to 1 master and 3 slave units
● Tool-less mounting to save valuable space in the cabinet
Remote Access
● Remote access via TCP/IP and built-in 10/100Base-T Ethernet port
● Support network communication protocols including TCP/IP, PPP, UDP, HTTP / HTTPS, TELNET, SSL, TFTP, SMTP, DHCP, SNTP, and DNS
● Support SNMP V1, V2 and V3
● Support Modbus RTU
Monitor
● Remotely monitor voltage / current / power / power factor / energy consumption at input circuit level
● Remotely monitor current / power / energy consumption at outlet level
● Remotely monitor circuit breaker on / off status (for models with CB only) and outlet status
● Rack environment monitoring via external connected T/H sensor
● Metering accuracy of +/-1%
Control and Configure
● Remotely control (switch on/ off / reboot) individual outlet
● User-defined sequential power on/ off delay
● Last known power on
● User-defined threshold settings of voltage / current / at input / circuit level
● User-defined threshold settings of voltage / current / at output level
● Support up to 5 user accounts with different administrative privileges
Mounting
● Rear button mounting
DCIM Ready
Managing iDC iPDU has never been more easier. Built-in template for monitoring real-time power consumption of iDC iPDU has been engineered into our DCIM System which makes integration with DCIM System within seconds!
Product Photo
